BT5226-HWL

Elements

Horizontal Wall Plate

For use with BT5226

BT5226-HWL/B

Elements

Horizontal Wall Plate

For use with BT5226

Enquire Today View Downloads

Overview

BT5226-HWL is an adaptor designed to mount the BT5226 double arm wall mount onto 16" stud walls. The horizontal plates offer a wider wall fixing option, converting the BT5226 from a single stud mount to a dual stud mount, simply add the adaptors onto the back of the BT5226 wall plate and continue with the screen installation.
BT5226-HWL is an adaptor designed to mount the BT5226 double arm wall mount onto 16" stud walls. The horizontal plates offer a wider wall fixing option, converting the BT5226 from a single stud mount to a dual stud mount, simply add the adaptors onto the back of the BT5226 wall plate and continue with the screen installation.

Product Features

  • Use wall plate adaptors with a BT5226 flat screen mount
  • Ideal for mounting across 16" stud walls
  • Simple assembly and installation
  • Mounts to the top and bottom of the BT5226 wall plate
  • All mounting hardware included
  • Also suitable for mounting to 10" and 12" stud walls
  • 100% plastic free packaging
  • Use wall plate adaptors with a BT5226 flat screen mount
  • Ideal for mounting across 16" stud walls
  • Simple assembly and installation
  • Mounts to the top and bottom of the BT5226 wall plate
  • All mounting hardware included
  • 100% plastic free packaging

Product Specifications

  • When attached to the BT5226 max load & screen size specifications remain the same as stated on the BT5226
  • Colour: Black
  • VESA compatibility: up to 600 x 400
  • Tilt: 12° downward / 2° upward
  • Screen levelling: +/-5°
  • Swivel: 180°
  • Distance from wall: Min: 57.6mm - Max: 497.8mm
  • Colour: Black
  • When attached to the BT5226 max load & screen size specifications remain the same as stated on the BT5226
  • Colour: Black
  • VESA compatibility: up to 600 x 400
  • Tilt: 12° downward / 2° upward
  • Screen levelling: +/-5°
  • Swivel: 180°
  • Distance from wall: Min: 57.6mm - Max: 497.8mm
  • Colour: Black

Ordering & Box Information

Order Code: BT5226-HWL/B

Barcode: 5019318309670

HS Code: 83024200

Single Box Item or Multi Box Item: Single Box Item

Total Boxed Weight (kg): 1.34kg

Order Code: BT5226-HWL/B

Barcode: 5019318309670

HS Code: 83024200

Single Box Item or Multi Box Item: Single Box Item

Total Boxed Weight (kg): 1.34kg
