• B-Tech's UltraGlide Tilt technology allows easy, secure screen adjustment
• Printed template for wall drilling makes installation quick and easy
• Swivel points enables quick, smooth screen positioning
• Ideal for mounting across 16" stud walls
• Integrated cable management throughout the mount
• Suitable for both landscape and portrait mounting
• Tilt can be locked at a selected angle
• Slim-line design allows close-to-wall installation when folded flat
• Lateral adjustment of screen after mounting
• Tool-less screen levelling
• Safety screws to prevent unauthorised screen removal
• Cover plates included for an attractive finish
• Simple 'hook-on' installation with all mounting hardware included
• 100% plastic free packaging

• Recommended display size: 42" up to 75"
• Max load: 50kg
• VESA fixings: up to 600mm x 400mm
• Tilt: +14°/ -3°
• Screen levelling: +/-3°
• Swivel wall mounted: 180°
• Swivel at interface: 180°
• Product width: 662.6mm
• Min product depth: 60.3mm
• Max product depth: 582.3mm
• Product height: 449.6mm
• Distance from wall - min: 52mm
• Distance from wall - max: 577mm
• Screen height adjustment: 20mm
• For Stud / Partition spacing: 16"
• Orientation: Landscape, Portrait
• Colour: Black

Order Code: BT8227/B

Barcode: 5019318307072

HS Code: 83024200

Single Box Item or Multi Box Item: Single Box Item

Total Boxed Weight (kg): 17kg
