• Designed to mount BT8390 horizontal rails and BT8393 vertical columns to walls and poles
• Mounts the BT8390 horizontal rail just 37mm from the wall with a +/-10mm adjustable depth to ensure a flat to the wall installation
• BT8390-WFK6 can also be pole mounted using B-Tech accessory collars
• Keyhole mounting for easy installation
• Micro-Adjustment of the height of the mounting rail with the supplied Hex Key allow for precision alignment
• Easy adjustment of the depth of the rails with a 13mm spanner ideal for counteracting uneven walls
• Integrated adjustment guides for straightforward alignment
• All mounting hardware included

• Designed for use with: BT8390 - Mounting Rail
• Max load: 50kg per bracket
• Product width: 56mm
• Min product depth: 57.3mm
• Max product depth: 77.3mm
• Product height: 310mm
• Adjustable depth: +/- 10mm
• Adjustable height: +/- 10mm
• Qty per pack: 1
• Colour: Black
• *Use B-Tech's online configuration tool to automatically calculate the quantity required based on your configuration

Order Code: BT8390-WFK6/B

Barcode: 5019318307287

HS Code: 83024200

Single Box Item or Multi Box Item: Single Box Item

Total Boxed Weight (kg): 1.32kg
